Product Features

1. Uses a high-performance 32-bit ARM microprocessor with a running frequency up to 48 MHz.

2. The BLHeli-32 firmware is developed based on BLHeli (code) and BLHeli-S (code), forming a third-generation BLHeli firmware.

3. Supports Damped Light mode. This mode not only enables regenerative braking for rapid motor deceleration, but also provides synchronous rectification.

4. This version of the firmware supports multiple functions to prevent motor desynchronization (loss of sync). Although the default settings work well under normal operating conditions, many parameters can still be adjusted to ensure stable operation even under demanding conditions.

5. The ESC supports standard PWM throttle mode, OneShot125 throttle mode, OneShot42 throttle mode, and MultiShot throttle mode.

6. The ESC supports digital throttle modes: DShot150 / 300 / 600 / 1200.

7. Includes a lost-model alarm function. If zero throttle signal persists for a period of time, the ESC will emit a beeping sound to help locate a lost aircraft.

8. Built-in 5V BEC, which can supply power to flight controllers, cameras, image transmitters, LED lights, and other devices.

⸻

Product Specifications

Model | Continuous Current | Burst Current (10s) | BEC | Battery Cells | Weight (reference) | Dimensions (reference)

F55APRO II 32 BIT
